Uncoiling→head removal→lead material leveling→vertical roll centering→cutting butt welding→vertical roll centering→edge milling machine→vertical roll centering→delivery→guide plate pressing→forming→inner welding→outer welding→cutting→steel pipe output.
| Serial number | Equipment composition | Quantity (set) |
| 1.1 | Uncoiler | 1 |
| 1.2 | Head removal machine | 1 |
| 1.3 | Primer leveler | 1 |
| 1.4 | Electric Vertical Roller | 3 |
| 1.5 | Edge milling machine | 1 |
| 1.6 | Manual stick | 1 |
| 1.7 | Delivery machine | 1 |
| 1.8 | Guide bar pressure row | 1 |
| 1.9 | Forming machine | 1 |
| 1.10 | Front axle unit | 1 |
| 1.11 | Internal welding device | 1 |
| 1.12 | External welding device | 1 |
| 1.13 | Rear axle unit | 1 |
| 1.14 | Centralizer | 2 |
| 1.15 | Cutting trolley | 1 |
| 1.16 | Embedded parts of front and rear axles | 1 |
| 1.17 | Hydraulic station | 1 |
| 1.18 | Electric control device | 1 |
| 1.19 | Submerged arc welding machine | 3 |
| 1.20 | Plasma cutting machine | 1 |
| 1.21 | Air compressor | 1 |
